RE: Estimations are as good as it can be, what else can be done here?

To add to what MWF said about hierarchical queries: “……. they are only correct if you are absolutely certain they don’t and never will prune intermediate layers of the hierarchies”

Clay Jackson
Database Solutions Sales Engineer
[cid:image001.jpg_at_01DA1B83.76B09280]<https://www.quest.com/solutions/database-performance-monitoring/> clay.jackson_at_quest.com<mailto:clay.jackson_at_quest.com> office 949-754-1203 mobile 425-802-9603

From: oracle-l-bounce_at_freelists.org <oracle-l-bounce_at_freelists.org> On Behalf Of Mark W. Farnham Sent: Monday, November 20, 2023 7:22 AM To: learnerdatabase99_at_gmail.com; 'Pap' <oracle.developer35_at_gmail.com> Cc: 'Jonathan Lewis' <jlewisoracle_at_gmail.com>; 'Oracle L' <oracle-l_at_freelists.org> Subject: RE: Estimations are as good as it can be, what else can be done here?

CAUTION: This email originated from outside of the organization. Do not follow guidance, click links, or open attachments unless you recognize the sender and know the content is safe.

If a small set of columns (like sometimes one column) can distinctly provide the top n ordering, it may be useful to provide that additional predicate, as an and x => y gathering up the data to present.

For slowly changing data and some “n” that it may even be useful to update a table containing the top “m” rows where “m” is as least as big as the biggest “n” your users will use and update that table if a new combination should be in it.

Going to such lengths would imply that these top “n” queries were quite important and worth quite a bit of engineering to optimize.

But you can. The generalized relation model and query optimizers are intended to make such engineering usually be unnecessary. But that doesn’t mean you CAN’T do it. You just have to be certain you get it right. (And beware injecting filters into hierarchical queries, because they are only correct if you are certain they don’t prune intermediate layers of the hierarchies.)

mwf

From: oracle-l-bounce_at_freelists.org<mailto:oracle-l-bounce_at_freelists.org> [mailto:oracle-l-bounce_at_freelists.org] On Behalf Of yudhi s Sent: Monday, November 20, 2023 5:14 AM To: Pap
Cc: Jonathan Lewis; Oracle L
Subject: Re: Estimations are as good as it can be, what else can be done here?

So basically two things here to get fastest possible time for these types of pagenation top n queries.. 1) Have the data available in one flattened table by doing all the joins and other operations among other tables before hand. 2) Have the index created in exact sorting order covering the filtered/joined and sort columns of the flattened table so that no additional sorting would be performed during runtime.

On Fri, 17 Nov, 2023, 4:54 pm Pap, <oracle.developer35_at_gmail.com<mailto:oracle.developer35_at_gmail.com>> wrote: "But yes sorting has to happen during run time only , we cant avoid the run time sorting by storing the results in sorted way before hand and just show it to the UI user upfront. Correct me if my understanding is wrong."

This above statement may not be accurate , as because if all of the columns which are part fetch + Filter + Joins + Sorting criteria can be added to an index and created exactly in same way as the sorting order, then the run time sorting can be eliminated.

Jonathan or others may comment.

On Fri, 17 Nov, 2023, 4:31 pm yudhi s, <learnerdatabase99_at_gmail.com<mailto:learnerdatabase99_at_gmail.com>> wrote: Thank you Jonathan. The blog you pointed is really awesome. It helps in getting an idea of how to approach the problem without throwing everything to the optimizer.

So basically its a two pass thing. The key strategy should be to get the sorting of the large record sets(Millions or billions) happen with minimal resources and that can only be achieved if all the column which are getting read(which should mostly be PK column or rowid) and the columns those are part of filter/join criteria + the sorting criteria ,are part of an index, so that it can be sorted as efficiently as possible. And then the related handful of rows can be fetched efficiently using the selected PK or Rowids and passed to the UI.

It may be challenging when the query is having Joins from multiple tables or the columns in select query or the sorting criteria are from different tables. But then flattening the data before or de-normalizing the results set such that they would be available in one single table(materialized view), will make the things easier in such situation.

But yes sorting has to happen during run time only , we cant avoid the run time sorting by storing the results in sorted way before hand and just show it to the UI user upfront. Correct me if my understanding is wrong.

On Wed, 15 Nov, 2023, 8:17 pm Jonathan Lewis, <jlewisoracle_at_gmail.com<mailto:jlewisoracle_at_gmail.com>> wrote: For examples where you have to select a large volume of data, sort it, and then return only the first few sorted results (pagination queries), you will find that sometimes the only thing to do is a complex rewrite of the query that tries to find the smallest amount of data that needs to be selected to allow the correct sorting followed by a "join back" by rowid or primary key to the tables that supply other non-sorted data.

There are some indications of technique at Manual Optimisation | Oracle Scratchpad (wordpress.com)<https://jonathanlewis.wordpress.com/2008/04/27/manual-optimisation/> with a 2nd and 3rd linked at the end of the article.

Regards
Jonathan Lewis

On Wed, 15 Nov 2023 at 05:18, Pap <oracle.developer35_at_gmail.com<mailto:oracle.developer35_at_gmail.com>> wrote: Jonathan/Andy,

The OP's query here is really doing a lot of work like passing ~2million rows all the way across 10+ table joins and also sorting all of them before publishing the first_n_rows to the client. But a common case could be like, a scenario in which the UI user has to see latest ~100 transactions details of certain type for a user within a date range(say one week/month). And in cases where the daily transaction can go up to 100's of millions and even a two table join criteria with an order by clause(for finding the latest transaction details based on date column) can take lot of time. So how should one handle the design of such a requirement?

Even one can have the de-normalized/flatten table or materialized view to persist the two table JOIN data before hand but the order is not guaranteed while we fetch the data, so we have to have the "order by date_column" clause added to the query on top of the materialized view scan(which might be on 100's of millions rows) , and that can well be the bottleneck then. How should one design to cater such user needs? Can Parallel processing help here?

 And it's also true that UI users don't understand about the detailed work it had to go through before publishing those handful of rows in the UI screen but they want it in a few seconds.

On Fri, Nov 10, 2023 at 6:27 PM Jonathan Lewis <jlewisoracle_at_gmail.com<mailto:jlewisoracle_at_gmail.com>> wrote:

It's not totally trivial working out the timing of activity in a parallel plan, although a good starting point is to follow the ordering given by the TQ details for each individual DFO tree. And the "Start Active / Time Active" is an interesting problem - presumably it's likely to cover the first slave start to the last slave ending time, which in unbalanced cases could lead to some confusion.

Looking at your plan here, though, the tablescan at operation 86 starts at +9 and takes 4 seconds to complete. I'm having a little difficulty working out exactly how this table scan passed through lagers of slave to get to the sort group by at operation 6 that starts at +12 and runs for 5 seconds - though that 5 seconds is probably about receiving data from the tablescan and join, and not really about sorting.

Given that it's a parallel query, it's not surprising that there are two sort group by operations - this is Oracle attempting to reduce the data size each PX slave has picked up from its hash join before distributing by range for a final sort group by. The sort group by at operation 3 starts at +16 and appears to take 24 seconds, but again I think very little time is spent in the actual sort, and most of the active time is related to passing the data to the client; the "PX SEND QC" is probably the indicator that the sort completed at +17.

Given that you seem to have 2M rows moving up the pipeline it's possible that the two-pass sorting could be eliminated. If you check the Outline Data you probably had a gby_pushdown(_at_qbname) in it. If you change this to no_gby_pushdown(_at_qbname) you should find that the preliminary sort group by disappears - this might make a couple of seconds difference. (I've had a draft note on that hint for 9 years but haven't got around to finishing it - there is a mention of it in https://jonathanlewis.wordpress.com/2022/04/13/adaptive-joins/ )

As far as a small amount of data making a big difference - that's always a possibility in any query. Given the complete cascade of hash joins, though, I don't think you're likely to see that happen. I have to say, though, that you do seem to have a skew in your data that might be adding a couple of seconds to your query. In the PX details you can see that slave p005 uses far more CPU time than the rest in slave set 1, and slave p00a does far more I/O to temp that the rest in slave set 2. Snapshots of PX session stats may give you some clues about those two anomalies.

Your general question about timing for 10 table joins with 2M rows - you've got more joins than that, and I can see 4, 5, and 8m rows reported, so plenty of work to do. 40 seconds doesn't seem unreasonable, until you say you only want to look at the first few. Possibly you could find a way to create a materialized view (perhaps of only a subset of the tables) that reduces that enough to make it look a lot better.

Regards
Jonathan Lewis

On Thu, 9 Nov 2023 at 10:51, yudhi s <learnerdatabase99_at_gmail.com<mailto:learnerdatabase99_at_gmail.com>> wrote: I ran the query manually with parallel(6) and below is the sql monitor. It does finish in ~40 seconds overall. But yes need to execute it from the UI by changing the view definition with parallel hint , to see howmuch extent its helping the real production run which runs with a first_rows kind of setup.

https://gist.github.com/databasetech0073/62b51587b3f590914e9a92218609672a

But again, if volume increase a bit the response time may again exceed and goes beyond ~10 second reponse which is not good experience for any UI user. So my doubt is, if we should really not expect these type of queries (e.g. with 10 table joins +~2million matching rows +sorting on top) to finish in <10 seconds and thus some different design approach should be followed to cater such requirement? Like persisting the transformed/aggregated results before hand in a materialized view or anything else?

--
