| Database design [message #163102] |
Tue, 14 March 2006 22:59  |
selvakumar_82
Messages: 138
Registered: October 2005
Location: chennai
|
Senior Member |
|
|
Hi friends,
I am working in a small company , We are not following any standard method for any projects.
But my TL said, I have to take care of database design for each project.
I need a guidence , How to develop a database design for any project.
What are the constraints i have to follow .....?
Any one share ur experience , It will be useful for me
If u dint understand my problem , Reply immediately.
Thanx in advance
regards
Selva.R
|
|
|
|
| Re: Database design [message #163125 is a reply to message #163102] |
Wed, 15 March 2006 00:27  |
 |
djmartin
Messages: 10181
Registered: March 2005
Location: Surges Bay TAS Australia
|
Senior Member
Account Moderator |
|
|
Okay, let's open this "can of worms". I expect that I will be flamed for many of my comments.
Use reasonably meaningful names for tables and fields. If they get too long then try to use fairly standard (but consistent) abbreviations. If in doubt, just remove the vowels (a, e, i, o, u).
For each table also have a three letter acronym. Then if you have an 'ID' field that is used in foreign key relationships, then put the three letter acronym before the '_ID' name in ALL the tables that use it including the owning table.
Always put you key fields first in the list of fields. Always put a width on number fields.
Develop a list of standard suffixes, for example:
_FL for flags (usually only Y and N)
_IND for indicators (typically single byte varchar2 fields)
_NO for numeric numbers
_NUM for character numbers
_DT for dates
_TS for date-time stamps
If you have a set of tables that are closely related then SERIOUSLY consider giving them the same prefix or name root.
David
[Updated on: Wed, 15 March 2006 16:01] Report message to a moderator |
|
|
|
| Re: Database design [message #163137 is a reply to message #163125] |
Wed, 15 March 2006 00:59 |
rleishman
Messages: 3728
Registered: October 2005
Location: Melbourne, Australia
|
Senior Member |
|
|
As far as object naming standards go, the advice above is as good as any. Most important is to BE CONSISTENT. Google "Database Naming Standards" and look at some of the documents you find - especially those on domains with .edu. - universities are red-hot on this sort of thing.
Also search for Oracle Database Design Standards, or variants of that phrase. Someone has done this already and will have published them on the web. (I have several times, but cannot publish them because I don't own the intellectual property).
Choose an appropriate database design tool. Oracle Designer is probably the best choice if it is part of your Oracle licence. ErWin is good too.
_____________
Ross Leishman
|
|
|
|
|
|
|
|
|
|
| Re: DBMS_PIPE [message #163525 is a reply to message #163522] |
Fri, 17 March 2006 01:40 |
selvakumar_82
Messages: 138
Registered: October 2005
Location: chennai
|
Senior Member |
|
|
It s a built in package in Pl/sql,
It provides a DBMS pipe service that ENABLES messages to be sent between sessions,
Regards
Selva
|
|
|
|
]
